HI5VPP fume cabinet
The structure of the cabinet is built in anodized aluminium section.
Filling with melamine wood 19 mm thickness and tempered glass
Fume hood cabin with lift-up door
Example of use :
– Application of products by spray
– Handling of chemical products in laboratory, varnishing…
– Suitable for cleaning solvents bins or machines exhaling a batch of fumes
Can be used two ways :
– As a recirculating (ductless) fume hood, using active carbon filter or particle filter
– Or with an external output (dust filter + exhaust duct Ø125 mm)
*Possibility of using protection prefilters for extending main filter lifetime
The cabin includes the structure as well as the engine box. Filters are sold separately.
Fume cabinet with one extraction group
Variable flow : 50 to 450 m3/h
Power : 80 W
L x H x D : 800 x 700 x 700 mm
Lift-up door with 200 mm hand clearance
Weight : 39 kg
Power Supply : 230 V / 50 Hz
Maintenance : Periodic change of the filter
Rear exit evacuation : Yes, Ø125 mm
Cabin with suction device
Variable flow: from 50 to 450 m3/h
Power: 80W
L x D x H: 800 x 700 x 700 mm
Lifting door with manual passage 200 mm
Weight: 39kg
Power supply: 230V / 50Hz
Maintenance: Changing the filter regularly
Rear output: Yes, external drain Ø125mm
